Velvac 100137 Tailgate Air Cylinder, 3.5" Bore, 8.68" Stroke

Part Number:810-100137
Not Yet Rated | Write the First Review
$221.09 USD
Velvac 100137 Tailgate Air Cylinder, 3.5" Bore, 8.68" Stroke
Processing...
Availability
Qty in Stock: 6
Add'l Qty (1-4 days): 10
Quantity in Stock reflects available inventory as of 5:00 AM CST.

Product Details


Special Notes
none
Product Description
Manufacturer: Velvac
Part Number: 100137
Tailgate air cylinder kit with extended clevis
Cylinder Type: Push/Pull
Diameter: 3.50"
Stroke: 8.68"
Retracted Length: 15.60" Clevis Center to Rod End
Extended Length: 22.28" Clevis Center to Rod End
Clevis Length: 4-15/16" Center of pin to end
Clevis Pin Diameter: 1/2"
Thrust: 962 lbs. @ 100 psi
Draw: 918 lbs. @ 100 psi
Max. Pressure: 120 psi

Tailgate air cylinders are designed to operate the lock linkage on dump bodies. They are NOT to be used to mechanically hold the tailgate shut.

Cross References: 810-100137, K1100-274, K1100274, 100137, TGC32508V, 400358, 29-35EX9, 29350X8, 100132
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
