Mico 02-520-202 Fixed Disc Brake Caliper, Hyd Oil, 2.5" Bore

Part Number:480-02520202
Not Yet Rated | Write the First Review
$644.21 USD
Mico 02-520-202 Fixed Disc Brake Caliper, Hyd Oil, 2.5" Bore
Processing...
Qty in Stock: Out of Stock
Quantity in Stock reflects available inventory as of 5:00 AM CST.

Product Details


Special Notes
none
Product Description
Manufacturer: Mico
Part Number: 02-520-202
NSN: 2530-01-521-6620
Mico CAGE Code: 92865
Condition: New
Fixed Disc Brake Caliper, Hyd Oil, 2.5" Bore
Fluid Type: Hydraulic Oil
Piston Diameter: 2.50"
Disc Diameter: 10" to 24"
Disc Thickness: 0.50"
Total Lining Contact Area: 15.74 Square Inches
Continuous Duty Pressure: 1500 PSI
Intermittent Duty Pressure: 2000 PSI
Caliper Material: Aluminum
Caliper Finish: Clear Anodized
Lining Thickness: 0.37"
Usable Lining Thickness: 0.37"
Lining Material: Non-Asbestos, Lead-Free
Porting: No. 4 SAE O-Ring; 7/16"-20

Cross References: 02-520-202, 480-02520202, 02520202, 619100, 2530-01-521-6620, 2530015216620
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
