Mico 01-530-045 Loaded Disc Brake Caliper, Brake Fluid, No Mounting Bracket
Part Number:480-01530045$632.77 USD
Product Details
- Special Notes
- none
- Product Description
- Manufacturer: Mico
- Part Number: 01-530-045
- Condition: New
- Disc Brake Caliper, Brake Fluid, No Mounting Bracket
- Includes Pre-Installed Brake Pads
- No Mounting Bracket
- Fluid Type: Brake Fluid
- Disc Diameter: 9.00" to Unlimited
- Disc Thickness: 0.50"
- Total Lining Contact Area: 7.82 Square Inches
- Continuous Duty Pressure: 1500 PSI
- Intermittent Duty Pressure: 2000 PSI
- Caliper Material: Ductile Iron
- Caliper Finish: Zinc Chromate Yellow
- Lining Thickness: 0.37"
- Usable Lining Thickness: 0.30"
- Lining Material: Non-Asbestos, Lead Free
- Piston Diameter: 2.37"
- Inlet Port: #4 SAE O-Ring Port: 7/16"-20 UNF
Cross References: 01-530-045, 480-01530045, 01530045
A cross reference listing means that this item should be a suitable replacement
for the part numbers listed. You should check the description to be sure it will work in your application.
