MEI 03-1405 Genuine OEM Sanden Compressor Replaces OEM#'s F69-6000, F69-6002-122 & LF0121

Product Details

Special Notes

none

Product Description

Manufacturer: MEI

Part Number: 03-1405

Condition: New

Genuine OEM Sanden Compressor

Volts: 12V

Clutch Diameter: 125mm

Grooves: 6 groove

Belt Type: Serpentine

Cylinders: 7 cyl

Displacement (ci): 9.5 cu.in.

Factory Oil Charge: 300cc Oil

Fitting Port Position: Lateral

Fitting Style: O-ring Pad @ 90 deg

Head Type: GQ

Wire Type: 2 Wire Female Packard #15300002

Replacement Clutch Assy.: 02-0606

Replacement Head Assy: 03-6552

Model: SD7H15HD

Oil Type: PAG100

Refrigerant Type: R134a

Rotation: CW

Shaft Type: Long Key Shaft

Diode Protection: w/diode

Truck Air Oring 1: 16-4208

Truck Air Oring 2: 16-4210

Truck Air Seal 1: 16-4208

Truck Air Seal 2: 16-4210

Application: Peterbilt Trucks

OEM Numbers: F69-6000, F69-6002-122, LF0121

Cross References: 03-1405, 475-031405, 031405, 4040, 4792, 1027U3, F69-6000, F696000, F69-6002-122, F696002122, LF0121
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
