Bendix 284795N DV-2 Drain Valve, Side Mount

Product Details

Special Notes

Exhaust must point at ground when installed

Product Description

Manufacturer: Bendix

Part Number: 284795N

DV-2 Drain Valve

Mounting: Side

Heater Cut-In: 45° +/- 10 °

Heater Cut-Out: 85° +/- 10 °

Supply Port (Top): 3/8" NPT (Plugged)

Supply Port (Side): 1/4" NPT Male

Heater: Yes

Heater Voltage: 12 Volts DC

Cross References: 284795, 284795N, 060-284795N, 5964010, SF5964010, SF599201, 101659, 104292, 104553, 104560, 107697, 284795X, 288783, 289796, 9934600264, 346-0264, 3460264, 346264, 25090000002, E0HT2A131CA, E5HT2A131CA, E0HZ2A131A, 6814320107, BW 281924, BW281924, BW 284795, BW284795, 700987, KN24005, 2530011654940, 4820010771187, 20QE19323P, 20QE19323P2, 20QE3350, 745-284795, 284795B1, 513594C92, 513596C91, 513596C92, 534314C91, BAN284795, BAR284795, ZAC284795, S-D970, SD970, 284795BXW, 61130304, 65002569, 27108422, 715030012, 9043417, G700987
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
